泉州方形座UCF带座轴承系列-UCF201型-国兴轴承-GUO轴承-福建泉州外球面带座轴承

品牌 GUO
类型 方形座UCF带座轴承-国兴轴承
型号 UCF201-201-203-204-205-206-207-208-209-210-211-212-213-214-215-216-217-218-305-306-307-308-309-310-311-312-313-314-315-316-317-318-319-320-322-324-326-328
15805094111
产品详情

福建泉州方形座UCF带座轴承系列-UCF201型-国兴轴承-GUO轴承-福建泉州外球面带座轴承-UCF201-UCF201-UCF203-UCF204-UCF205-UCF206-UCF207-UCF208-UCF209-UCF210-UCF211-UCF212-UCF213-UCF214-UCF215-UCF216-UCF217-UCF218-UCF305-UCF306-UCF307-UCF308-UCF309-UCF310-UCF311-UCF312-UCF313-UCF314-UCF315-UCF316-UCF317-UCF318-UCF319-UCF320-UCF322-UCF324-UCF326-UCF328


英制UC外球面轴承内径尺寸


型号
内径尺寸mm
型号
内径尺寸mm
UC201-08
12.7    (1/2)
UC210-32
50.8    (2)
UC202-09
14.288    (9/16)
UC211-32
50.8    (2)
UC202-10
15.875    (5/8)
UC211-33
52.388   (2-1/16)
UC203-11
17.463    (11/16)
UC211-34
53.975   (2-1/8)
UC204-12
19.050    (3/4)
UC211-35
55.563   (2-3/16)
UC204-13
20.638   (13/16)
UC212-36
57.15       (2-1/4)
UC205-13
20.638   (13/16)
UC212-37
58.738   (2-5/16)
UC205-14
22.225    (7/8)
UC212-38
60.325   (2-3/8)
UC205-15
23.813    (15/16)
UC212-39
61.913   (2-7/16)
UC205-16
25.4    (1)
UC213-39
61.913   (2-7/16)
UC206-17
26.988    (1-1/16)
UC213-40
63.5    (2-1/2)
UC206-18
28.575    (1-1/8)
UC213-41
65.088   (2-9/16)
UC206-19
30.163    (1-3/16)
UC214-42
66.675   (2-5/8)
UC206-20
31.75       (1-1/4)
UC214-43
68.263   (2-11/16)
UC207-20
31.75       (1-1/4)
UC214-44
69.85       (2-3/4)
UC207-21
33.338    (1-5/16)
UC215-45
71.438    (2-13/16)
UC207-22
34.925    (1-3/8)
UC215-46
73.025    (2-7/8)
UC207-23
36.513    (1-7/16)
UC215-47
74.613   (2-15/16)
UC208-24
38.1    (1-1/2)
UC215-48
76.2       (3)
UC208-25
39.688    (1-9/16)
UC216-49
77.787   (3-1/16)
UC209-26
41.275     (1-5/8)
UC216-50
79.375   (3-1/8)
UC209-27
42.863    (1-11/16)
UC216-51
80.962   (3-3/16)
UC209-28
44.45       (1-3/4)
UC217-52
82.55       (3-1/4)
UC210-29
46.038    (1-13/16)
UC217-53
84.137   (3-5/16)
UC210-30
47.625    (1-7/8)
UC217-55
87.313   (3-7/16)
UC210-31
49.213    (1-15/16)
UC218-56
88.9       (3-1/2)
